Procella DA05-DSP

24.490kr

Procella DA05-DSP er en avansert og kraftig effektforsterker med DSP til å styre Procella subwoofere. Preset EQ for alle mindre Procella-modeller.

Produsert av legendariske Procella Audio.

  • Preset EQ
  • Avansert DSP
  • 2 x 300W i 8 ohm
  • 19″ Rack-ører
  • THX-godkjent


Beskrivelse

DA05-DSP

With utterly transparent sound quality and huge power reserves for tremendous dynamic range, the DA05-DSP is truly the ultimate amplifier for Procella speakers!


Great speakers need a great amplifier, and that is the reason we created the DA05-DSP. It further increases the audio quality that Procella loudspeakers and subwoofers are famous for. Whether you are building a top class home cinema, studio or Premier class commercial cinema. The DA05-DSP is a 1,200 Watt two-channel power amplifier that delivers 600W x 2 into 4 ohms and 300W x 2 into 8 ohms. The amplifier’s class-D design is highly efficient, producing enormous output in a chassis that is only 1 RU high.

The amplifier has onboard DSP with factory programmed presets. They provide active crossovers and precise EQ for Procella’s full-range speakers and subwoofers. The factory presets cover the majority of system configurations. For unique system requirements, custom DSP programming is available on an advance order basis. With utterly transparent sound quality and huge power reserves for tremendous dynamic range, the DA05-DSP is truly the ultimate amplifier for Procella speakers!

Spesifikasjoner

GENERAL1200 W, 2 channels (not bridgeable), Output current 16 Arms, Output voltage 70 v / 50 Vrms / 36.2 dBu
MAXIMUM TOTAL OUTPUT POWER16 ohms 150 W, 2 ohms 500 W, 4 ohms 600 W, 8 ohms 300 W
PERFORMANCEChannel seperation @ 1 kHz > 80 dB, Frequency respons 2 Hz – 42 kHz (-3 dB), Gain (all DSP controls set to 0 dB) 30.2 dB, Signal To Noise Ratio 102 dB
MAINS POWERconnector Locking IEC inlet, nominal 100-240 VAC, operating 60-265 VAC, Standbye <6.5 W
PHYSICALDepth ( Rack rail – rear panel) 272mm, Depth (over all) 344 mm, Finish Black/Grey steel chassis, W x H  1U / 483 x 44 mm /  4.6 Kg
CONNECTIVITYAES input 3-pin XLR female, AES input link 3-pin XLR male, Analog input 3-pin XLR female, Analog input link 3-pin XLR male, Network RJ45 (ethernet), Output Neutrik speakON / binding posts / electronically balanced
APPROVALSCCC, CE, FCC, PSE, RCM, UL (ANSI/UL, CAN/CSA)
